NGCL型聯軸器主要參數及尺寸：
|
型號 |
公稱轉矩Tn N.m |
許用轉速 {n} t/mi |
軸孔直徑 |
軸孔長度 |
D |
D1 |
D2 |
C |
C1 |
B1 |
DO |
BO |
轉動慣量Kg.m2 |
重量Kg |
|
|
Dz d |
L |
||||||||||||||
|
Y |
J1ZI |
||||||||||||||
|
NGCL1 |
335 |
4000 |
20-35 |
52-83 |
38-60 |
103 |
71 |
50 |
30 |
8 |
42 |
160 |
68 |
0.071 |
8 |
|
NGCL2 |
630 |
4000 |
25-45 |
62-112 |
44-84 |
115 |
83 |
60 |
36 |
8 |
48 |
160 |
68 |
0.083 |
11 |
|
NGCL3 |
1000 |
3800 |
28-56 |
62-112 |
44-84 |
127 |
95 |
75 |
41 |
8 |
49 |
200 |
85 |
0.187 |
17 |
|
NGCL4 |
1600 |
3800 |
38-65 |
82-142 |
60-107 |
149 |
116 |
90 |
41 |
8 |
53 |
200 |
85 |
0.264 |
23.8 |
|
NGCL5 |
2800 |
3000 |
40-75 |
112-142 |
84-107 |
167 |
134 |
105 |
48 |
8 |
28 |
250 |
105 |
0.607 |
34.4 |
|
NGCL6 |
4500 |
3000 |
45-90 |
112-172 |
84-132 |
187 |
153 |
125 |
49 |
9 |
59 |
250 |
105 |
0.795 |
47.6 |
|
NGCL7 |
6300 |
2400 |
50-100 |
112-212 |
84-167 |
204 |
170 |
140 |
53 |
9 |
63 |
315 |
132 |
1.388 |
71.1 |
|
NGCL8 |
9000 |
1900 |
55-110 |
112-212 |
84-167 |
230 |
186 |
155 |
64 |
12 |
77 |
400 |
168 |
4.072 |
108 |
|
NGCL9 |
14000 |
1500 |
60-130 |
142-252 |
107-202 |
256 |
212 |
180 |
71 |
13 |
80 |
500 |
210 |
10.109 |
167 |
|
NGCL10 |
20000 |
1200 |
65-150 |
142-252 |
107-202 |
287 |
239 |
200 |
65 |
15 |
90 |
630 |
265 |
29.248 |
237 |
|
NGCL11 |
31500 |
1050 |
70-170 |
142-302 |
107-242 |
325 |
276 |
235 |
77 |
16 |
94 |
710 |
298 |
47.08 |
357 |
|
NGCL12 |
45000 |
1050 |
75-200 |
142-352 |
107-282 |
362 |
313 |
270 |
94 |
17 |
104 |
710 |
298 |
53.69 |
464 |
|
NGCL13 |
63000 |
950 |
150-220 |
252-352 |
202-282 |
412 |
350 |
300 |
88 |
18 |
113 |
800 |
335 |
86.67 |
596 |
|
NGCL14 |
100000 |
950 |
170-250 |
302-410 |
242-330 |
462 |
420 |
335 |
92 |
20 |
157 |
800 |
335 |
105.9 |
850 |
